Detect damage to the spindle quickly

Spindle taper control

Andrea Gillhuber, 31.05.2019, 06:05

Detect damage to the spindle quickly

With the ceramic Dyna Contact taper gauge from Big Kaiser, the machine spindle taper can be quickly checked for damage and incorrect angles.

Ceramic taper gauge Dyna Contact from Big Kaiser. © Big Emperor

To check the spindle, an operator applies blue ink to the gauge. When the gauge is removed, deviations in the color coverage become visible. This allows the operator to easily check the taper contact and assess whether the machine spindle is making perfect contact with the tool holders.

Dyna Contact is available for 30 mm, 40 mm and 50 mm spindles and can be used for BBT (BT=JISB6339), BDV (DV=DIN69871) and BCV (CV = ANSI). The ceramic taper gauge is supplied in an aluminum case.
