These are made of special aluminum or steel tubing that folds as intended in the event of a crash and converts the kinetic energy into heat. The machine elements protect structures in the event of an accident through high, uniform energy dissipation of 98 percent. The crash dampers from ACE shock absorbers offer great long-term stability in everyday operation as well as excellent protection in the event of an emergency stop. They are also easy to install and replace after a crash.

Receptive disposable solutions

The new crash dampers provide design engineers with a highly effective and economical one-way solution to effectively protect systems or machines. They therefore represent an interesting alternative to irreversible and reversible structural dampers and hydraulic safety shock absorbers. The new safety products from ACE are made of specially designed aluminum tubing or steel with external diameters of 87.5 mm in the aluminum versions and 63 mm and 38 mm in the steel versions. Ten basic types are available as standard, with energy absorption in emergency stop applications ranging from 670 Nm/stroke to 11,200 Nm/stroke. Depending on the type, the maximum stroke of the components is between 45 mm and 160 mm, whereby the low support forces of 13,000 N to 70,000 N make a decisive contribution to securing structures. In practice, these values can be increased even further by arranging the crash dampers in series or in parallel in order to reduce higher energy values than those mentioned in one go.

Other advantages of the emergency stoppers developed in sophisticated test series include simple installation, easy retrofitting in existing systems, quick replacement and reduced downtime after a crash. In addition, the crash event can be reconstructed from the deformation of the element and, in the best case, avoided in the future. The new crash dampers can be delivered from the Langenfeld warehouse within 24 hours and are characterized by a good price-performance ratio. The basic types are already reliably securing linear units in robotics as well as the end positions of machine tools, conveyor systems and high-bay storage and retrieval machines in many places. ACE also offers customized types, which the company can supply on request.
