Integrated encoder
Just a few millimeters for precisely fitting encoders
Faulhaber has added a model with an integrated magnetic encoder to its BXT motor family.
The BXT motor family, which consists of brushless DC motors with a particularly short design, has been expanded to include the diameter-compliant magnetic encoder IEF3-4096. With an additional length of just 6.2 millimetres, the motor/encoder units also remain extremely short. In addition, the encoder is fully integrated into the robust motor housing.
In this flat design, the IEF3-4096 offers three channels with index function and a high resolution of up to 4096 pulses per revolution. The IEF3-4096 L is also available as a variant with a line driver. The encoder can be combined with the housed BXT motors 2214...BXT H, 3216...BXT H and 4221...BXT H.
The combination of BXT motors with the IEF3-4096 encoder is the ideal solution when precise positioning is required in confined spaces and high torques are required at the same time. Typical applications include robotics, medical technology, laboratory automation and industrial automation. The encoder is connected with a ribbon cable, suitable connectors are available. dsc
